Parameteres Range
1 O2 : 0 - 25%
2 CO : 0 - 20.000 ppm
3 NO/ NOx : 0 - 5000 ppm
4 NO2 : 0 - 1000 ppm
5 SO2 : 0 - 5000 ppm
6 H2S : 0 - 1000 ppm
7 IR-CxHy : 0 - 100%
8 IR-CO2 : 0 - 100%
Display size : Graphical - LCD, with backlight and
variable contrast, 128x112pixels, 75x64mm
- Printer : High-speed dot matrix printer with graphic
capability for 57mm normal papers
- Data memory : Memory for 30 reports and 10 banks
containg a total of 1024 set of data
- Interface : RS232C
- Power supply : 110/ 220V AC 50 ÷ 60Hz
- Charging time : Lead-acid battery 12V / 2.2Ah, charging
time 10 h working time approx. 6h
- Gas pump : Membrane pump, electronically regulated
at 90l/ h
- Probe : Probe Heated for soot test
- Probe length : Probe length 300 mm
- Length of gas line : Length of gas line 3 m
- Gas filter : Gas filter In line filter 20 ¼ m
- Dimension : 270 x 175 x 245mm
- Weight : ± 6, 2 kg
- Accessories : Probe 300mm, Internal printer, certificate Calibration
RS232-Interface cable, Utility CD, and case
