Parameteres Range
1 O2 : 0 - 25%
2 CO : 0 - 20.000 ppm
3 NO : 0 - 5000 ppm
4 NO2 : 0 - 1000 ppm
5 SO2 : 0 - 5000 ppm
6 H2S : 0 - 1000 ppm
7 IR-CxHy : 0 - 100%
8 IR-CO2 : 0 - 100%
• Display size : LCD, with backlighting , 320 x 240 Pixel
• Printer : Internal dot matrix printer 57 mm wide
• Data memory : 256 MB memory to facilitate continuous
: storing of results
• Interface : RS232C
• Power supply : 110/ 230 VAC 50/ 60 Hz
• Battery : Lead-acid battery 12V / 2.2Ah, charging
: time 10h working time approx. 6h
• Gas pump : Gas pump Membrane pump
• Probe : Probe Heated for soot test
• Probe length : 300 mm ( other options available)
• Length of gas line : Length of gas line 3m
• Gas filter : Gas filter in line filter 5¼ m and 20 ¼ m
• Size/ Weight : 500x410x180 / 9, 5kg
